Name: Brass High Frequency Rotary Joint With Small Size Radar Antennas Fiber Optic Slip Rings
Brand: Brass High Frequency Rotary Joint With Small Size Radar Antennas Fiber Optic Slip Rings
SKU: LPCC-01B
Rating: 5 (130 reviews)

Caratteristiche Galleria Descrizione di prodotto Richieda una citazione

Caratteristiche

Specificazioni

Model Number: LPCC-01B

Frequency Range: DC to 6 GHz

Rotating Speed , Max: 100rpm

Nut Material: Brass

Body Material: Stainless Steel

Informazioni di base

Model Number: LPCC-01B

Termini di pagamento e spedizione

Descrizione di prodotto

Product Description

Bargain Price Only in Alibaba

JINPAT single-channel high frequency slip ring offers high frequency transmission solution between a fixed platform and a rotary platform, such as TV cameras, unmanned aerial vehicles and radar systems.

The slip ring allows signal transmission in the frequency range from DC up to 6GHz, and it can be integrated into the electrical slip ring to transmit power and high speed data. The high frequency slip ring is identified as ease of installation, ease of maintenance and optimal life.

Features

Connector type: SMA-K
Frequency range: DC-6GHz
Insertion Loss: within 0.3dB
VSWR: within 1.4
Working speed: 100RPM
Lifespan: 1 million

Main Application

Vehicle Turrets
Radar Antennas
Remotely Operated Vehicles
Video Surveillance Systems
Traffic Systems

Product parameters

Frequency Range	DC to 6 GHz
Rotating Speed , Max	100rpm
Nut Material	Brass
Body Material	Stainless Steel

Product Image
